The BESSEY BEYCEPS construction jack is a revolutionary one-handed assembly tool that combines power, precision, and safety. With a lifting capacity of up to 180 kg (400 lbs), this versatile tool is designed for professionals and DIY enthusiasts alike. Whether you’re installing cabinets, aligning doors, or handling heavy construction elements, the BEYCEPS ensures ergonomic, precise, and safe lifting, lowering, and clamping with just one hand. Model: BEY23
Key Features of the Bessey BEYCEPS Construction Jack:
Powerful & Versatile
- Lifting force: 1,800 N / 180 kg / 400 lbs
- Stroke per pump: up to 8 mm
- Fine lowering: up to 4 mm per lever actuation
- Usable lifting range: 5–230 mm
- Clamping range: 170–390 mm
- Rail dimensions: 22 x 8 mm
- Weight: 1.6 kg
Ergonomic & Intuitive Handling
The 2-component pump handle is placed on the top for easy operation. Two separate levers below allow fine lowering and quick release without accidental activation. This design ensures comfortable and safe one-handed control.
Protection for User & Workpiece
- Closed plastic housing: Protects mechanics from dust, dirt, chips, and prevents finger injuries.
- Protective caps (included): Prevent damage to sensitive surfaces such as floors, cabinets, or countertops.
- CE-certified: Meets European safety standards.
Large Usable Range & Flexibility
- Minimum clearance: only 5 mm (flattest in its class).
- Tool-free conversion for clamping up to 390 mm.
- Optional BEY-IK Installation Kit expands usable area up to 620 mm, ideal for wall cabinets and furniture installations.
Applications – Where the BEYCEPS Excels
The BESSEY BEYCEPS Construction Jack is ideal for construction, workshop, renovation, and DIY projects. Common uses include:
- Kitchens & cupboards – precise alignment and installation
- Doors & windows – safe lifting and positioning
- Floors, decking & cladding – controlled leveling
- Household appliances & furniture – effortless installation
- HVAC systems & support beams – strong, reliable lifting
- Metal & wood construction – dust-protected mechanics for workshop use
Why Choose the BEYCEPS?
The BESSEY BEYCEPS sets a new standard in assembly technology:
- Safe & ergonomic one-handed operation
- Powerful lifting up to 180 kg
- Gentle, millimeter-precise adjustments
- Protection for both user and materials
- Quick, tool-free conversion to clamping
- Durable, dust-protected housing
Whether you’re a construction worker, carpenter, installer, or DIY enthusiast, the BESSEY BEY23 BEYCEPS is an indispensable tool that makes lifting, lowering, clamping, and aligning heavy objects faster, safer, and easier.
Technical Data:
- Max weight capacity: 180 kg (400 lbs)
- Lifting stroke: up to 8 mm per pump
- Fine lowering stroke: up to 4 mm per actuation
- Usable lifting/spreading range: 5–230 mm
- Clamping range: 170–390 mm
- Rail: 22 x 8 mm
- Weight: 1.6 kg
- Model Number: BEY23
- EAN: 4008158050973
The BESSEY BEYCEPS is more than just a construction jack – it’s a multi-purpose, ergonomic, and safe assembly solution that saves time and effort on the job. With its robust lifting power, precision control, and protective design, it’s the ideal tool for professionals and ambitious DIYers.
